Dayton Audio HARB252-8 1″ x 5″ Dual Motor High Aspect Ratio Speaker Driver 8 Ohm

Dayton Audio HARB252-8 1″ x 5″ Dual Motor High Aspect Ratio Speaker Driver 8 Ohm Overview:The Dayton Audio HARB252-8 1″x 5″ full-range driver features a uniquely narrow form factor whose shape is implemented by employing tandem magnetic assemblies. Product Highlights:High Aspect Ratio transducer fits in unconventional enclosuresDual neodymium magnet motors maintain narrow mounting profileAmazing off-axis frequency responseGreat for use in line arrays and low profile bar speakers Product Description:The unique shape and full frequency range of Dayton Audios HARB252-8 1″x 5″ dual motor full-range driver permits applications where other drivers simply won’t fit. Place it horizontally as the mid or full-range driver for a center channel/monitor stand, or vertically as a desk-top/computer speaker. Product Details:BrandDayton AudioModelHARB252-8Part Number295-246UPC848791001871Unit of MeasureEachWeight0.2 Product Specifications:Nominal Diameter1*5″Power Handling (RMS)10 WattsPower Handling (MAX)15 WattsImpedance8ΩFrequency Response150 to 17,000HzSensitivity77.2dB 2.83V/1mVoice Coil Diameter0.63″ Thiele-Small Parameters:Resonant Frequency (Fs)172.11HzDC Resistance (Re)7.2 ohms.Voice Coil Inductance (Le)0.09 mHMechanical Q (Qms)4.23Electromagnetic Q (Qes)2.98Total Q (Qts)1.74Compliance Equivalent Volume (Vas)                        0.01ft³Mechanical Compliance of Suspension (Cms)0.305mm/NBL Product (BL)3.039T·mDiaphragm Mass Inc. Airload (Mms)3.24gMaximum Linear Excursion (Xmax)1.25mmSurface Area of Cone (Sd)21.03cm² Materials of Construction:Cone MaterialFiberglassSurround MaterialRubberVoice Coil Wire MaterialCopperVoice Coil FormerKapton® / PolyimideBasket / Frame MaterialPolymerMagnet MaterialNeodymium Mounting Information:Overall Outside Diameter1.185″ x 5.15″Baffle Cutout DiameterOval: 1″ x 4.75″Depth1.16″# Mounting Holes4 Enclosure Volume:Sealed Volume0.026ftSealed F3128Hz Dayton Audio HARB252-8 Graphs/FRD/ZMA Data FileDayton Audio HARB252-8 Spec SheetDayton Audio Manufacturer Warranty
