DAC – Z5G0285W 5″ Sealed-Back Midrange Speaker 8 Ohm

$ 5.70

*200 denier nylon
*Heading & grommets
*All hemmed edges

Please allow up to 2 weeks for some colors. Any other colors on the stock nylon color chart can also be made for $36.00 each (single-color) or $40.00 (two-color).

Call for availability.

DAC – Z5G0285W 5″ Sealed-Back Midrange Speaker 8 Ohm Overview:The Z5G0285W 5″ Sealed-Back Midrange Speaker utilizes a paper cone, foam surround and sealed frame for simple installation in a 3-way speaker system. Product Details:BrandDACModelZ5G0285WUnit of MeasureEachWeight0.8 Product Specifications:Nominal Diameter5″Bolt Circle Diameter4.75Power Handling (RMS)5 WattsPower Handling (MAX)10 WattsImpedance8ΩFrequency Response600 to 8,000HzSensitivity90.81dB 2.83V/1mVoice Coil Diameter0.75″ Thiele-Small Parameters:Resonant Frequency (Fs)592.2HzDC Resistance (Re)6.841ΩVoice Coil Inductance (Le)0.274mHSurface Area of Cone (Sd)73.9cm² Materials of Construction:Cone MaterialPaperSurround MaterialFoamVoice Coil Wire MaterialCopperVoice Coil FormerPaperBasket / Frame MaterialSteelMagnet MaterialFerrite Mounting Information:Overall Outside Diameter5.125″Baffle Cutout Diameter4.375″Depth1.75″# Mounting Holes4
