SB Audience ROSSO-34CD-PK Compression Driver 1″

SB Audience ROSSO-34CD-PK Compression Driver 1″ Features:PEEK diaphragmOptimized cast aluminium rear chamber with dampingWide useful bandwidthSmooth frequency and impedance responseAdvanced voice coil with flat copper clad aluminum wire Product Specification:Nominal Impedance8 OhmRDC6 OhmAES Power Handling (1)30 WMaximum Power Handling (2)60 WSensitivity (1W/1m)(3)105 dBFrequency Range1000 – 20000 HzRecommended Crossover Frequency2.5 kHzVoice Coil Diameter34 mm (1.34 in)Winding MaterialFlat copper clad aluminiumFormer MaterialKaptonWinding Depth2 mm (0.079 in)Magnetic Gap Depth2 mm (0.08 in)Diaphragm MaterialPolyether ether ketone (PEEK)Flux Density1.3 TMagnetFerriteDemodulation–Phase Plug DesignAnnularExit Angle29.80° conicalNET Air Volume filled by HF Driver0.21 liters Dimensions & Weight:Throat Diameter25.4 mm (1 in)Overall Diameter90 mm (3.5 in)90° Mounting Holes Diameter (4xM6)76 mm (3.0 in)Depth45.86 mm(1.80 in)Net Weight0.94 kg (2.07 lb)Shipping Box109 X 94 X 50 mm(4.29*3.70*1.96 in)Gross Weight0.97 Kg(2.13 lb)  ROSSO-34CD-PK Drawing: ROSSO-34CD-PK Frequency Response:   Note :Driver mounted on Horn H250(1) 2 hour test made with continuous pink noise signal within the range from      the recommended crossover frequency to 20kHz.(2) Maximum power is defined as 3dB greater than nominal power.(3) Averaged within the frequency range (2kHz – 18kHz)ROSSO-34CD-PK Specifications Please Click Here.Note:  Shipping charges may vary based on Area/Weight of the product so kindly contact us before placing the order
